Electro-Optic Deflectors (lithium niobate or lithium tantalate for general applications)
PN Number
ED1
ED2
ED3
Aperture
1mm
2mm
3mm
Deflector length
11mm
20mm
25mm
Deflection angle for 1kV drive
5mrad
3mrad
1.5mrad
Optical loss ar/ar at 1.06um
< 1%
Dimensions
(excluding connections)
25 x 25 x 11 mm
20 x 20 x 31 mm
Connector
SMA
Capacitance
50pF
Switching Speed
Driver limited
Solid State 20kHz Driver Specification
Power Input
+9V or +12V @ 0.7A D.C.
Output
+900V pulse
Nominal Pulse Length
20 - 100ns, internally adjustable
Rise Time into 50pF Capacitor
￡10ns
Trigger Input
2 - 5V with 10ns rise time into 50
Repetition Rate
0 - 20kHz
60 x 60 x 110mm
Connectors: Output & Trig. in
Cable length between Pulser and Deflector
500mm max.
